Music Studio / Attic Conversion above Garage in Woollahra.
50mm Nude White Queitspace panels – Cut to size.
Price $ 380 per panel.
The combination of the panel thickness/ low ceiling heights and coverage -resulted in the internal sound / echo /reverb times were reduced significantly,
The resulting noise level inside the room was reduced and also the noise leaving the room was also reduce to the neighbours joy.
There was also a removal panel to sit inside the window when the room was in use.
Australian Museum
Gallery Conversion
Black Quietspace 50mm panels @ 1200 x 1200 Direct fixed with adhesive to the existing black Ceiling
Concrete poles lined with Custom Cut 50mm panels above non permanent flats $380 per panel
Internal Studio Construction
Studio fabricated completely in Warehouse Conversion Space – Free-standing isolated.
Fixed to concrete Slab with Mechanical Anchors and Isolation Mounts
Fixed to walls with Isolation Mounts and Anchors
Sliding 900mm/ 40mm Solid Core door on barn rails.
Studio is completely removal with fasteners.
All noise is completely contained.
Contruction Method:
25mm MDF external
90mm Stud Walls
32kg/75mm Polyester Infill Insulation
25mm MDF Internal
25mm Quietspace / 16mm MDF Perforated (50%) Coverage
50mm Quietspace Black Panels
LVL Highspan timber Frames
Yellow tounge Ceiling and floors.
60kg /50mm Acoustic Blanket x 2 layers Internal Ceiling Insulation
Australian Navy Base Cafe – HMAS Penguin
Historical Building with noise issues from rowdy hungry sailors.
Wall lines with 50mm White Queitpsace panels – Full Coverage.
Poles lined with 50mm Black Quietspace Panels.
Signage above service area lined with Panels and trims.
All edges dressed with powder coated Aluminium angle for improved asthetics and wear in high use areas.
NSW Primary School Library
Existing library in multi use building.
Clear 6mm Perspex sheets fabricated on site over existing barrier to enclose learning space form the multi level / use building.
White Quietspace 25mm Panels installed to the ceiling in between existing lighting layout ti reduce internal echo and reduce classroom noise.
White 25mm $240 per panel –
Cafe
25mm Nude White Ceiling Panels
1200 x 1200mm Installed to 4-6 meter high existing raked ceiling on both sides of the large room.
Being used as a Commercial cafe the floor was a highly reflective cleanable surface.
High Coverage panel ratio > 85%.
The layout and consistency of the panels installed across the room was able to contain the echo caused by noisy Patrons.
Each area of the cafe was effectively isolated from the other, and noise did not travel from end to end.
Being an aged care home this was of great benefit to the patients with any hearing conditions as they are now able to talk and hear in the cafe at all times.
We also work with Licensed Carpenters and tradesmen, professional Installers. We supply customers with all Professional Acoustic Insulation required to achieve Noise free solutions in various environments; in the build stage and retrofit, or interior fitout. Acoustic Insulation Absorption Panels & Polyester Infill, Noise Barrier products, and the newer Designer Acoustic baffles and Diffusers that suspend from the Ceiling, Acoustic Door solutions and seals. We use the best products availble from various national suppliers to ensure the right solution, and have no self made products to sell. Our speciality lies in where we started in the Music , Audio and Media Industries and we apply that knowledge to the users of today. We are very focused on making the noise go away, and work at the highest standards.
Absorber Noise Barrier Composite Sorberbarrier is a unique acoustic composite product combining the superior soundproofing performance of the flexible mass loaded vinyl, Wavebar, with Pyrotek’s Sorberfoam. The product is designed to reduce unwanted sound in applications such as HvAC systems, equipment enclosures, recreational crafts, smaller marine vessels
SOUND ABSORBER FOR CHALLENGING ENVIRONMENTS • Exceptionally high Noise Reduction Coefficient (NRC) • Unique, non-combustible glass-based material • No smoke emissions • Weather, water and UV resistant Reapor® panels are made from recycled glass granules, using a patented German process. The granules are fused together to form
Soundlag is a high-performance composite acoustic lagging product developed to reduce noise from pipes, valves, fan housings, and ductwork in commercial, industrial and domestic buildings. Soundlag 4525C provides an optimal soundproofing solution for those seeking compliance to BCA (Building Code of Australia) F5.6 requirements for habitable and
Sorberpoly™ 2D acoustic insulation is a fine fibre, non-woven polyester, with excellent sound absorbing and thermal insulation properties, useful in high humidity applications. It is fuel, oil and grease resistant. Under normal applications, the material will last a life-time. It’s a lightweight, hydrophobic (non-wicking) product which is
dBX Flexible Noise Barrier with Aluminium Glass-Cloth Facing Quadzero™ dBX is a high performance noise control product that exhibits superior transmission loss performance. It features a flexible, mass-loaded, noise barrier, laminated with an aluminium foil-covered glass-cloth facing, (AGC). It was developed to meet market requirements in marine,
Echohush Profile is a range of decorative sound absorbing foam panels made from combustion modified polyether foam, that offer diffusive properties as well as high noise reduction across a broad frequency range. As the name suggests, the absorptive panels feature a variety of decorative profiled surface patterns
Echohush Bass Traps are acoustic foam absorbers made from combustion modified foam that are tuned to absorb lower frequencies. The panels absorb low frequencies preventing them from reflecting back into the room thereby controlling standing waves, that can generate low frequency ’boomy’ noise. Controlling reflected sound energy
In the last few years we have also installed Soundpoofing to Schools, Doctors, CourtRooms, Offices, Treatment Rooms. We use professional Installers, or can supply only.
